jspsych-ado

Adaptive design optimization (ADO), entirely in the browser, for jsPsych experiments.

Overview

jsPsychADO runs adaptive jsPsych experiments: instead of a fixed trial list, it picks each trial's stimulus to be the most informative one for estimating your participant's parameters — so you learn more from fewer trials.

Under the hood, after each trial (or block of trials) a Stan model — compiled to WebAssembly and run in a Web Worker via tinystan — estimates the posterior over your model's parameters, and the next design is chosen by maximizing mutual information over a grid of candidate designs. There is no server and no Python: everything runs client-side, so an experiment deploys as static assets.

You bring a task (design grid + presentation) and a model (Stan likelihood + a small JS adapter); jsPsychADO checks that they are compatible and turns them into an adaptive jsPsych timeline. Responses can be binary, finite-categorical, or continuous — the engine enumerates outcomes for discrete responses and integrates the predictive density for continuous ones. Or start from one of the bundled model packages and adapt a demo's task code — every demo is ordinary jsPsych experiment code, ready to copy.

Status

🚧 Early release — published on npm as jspsych-ado (npm install jspsych-ado; current version in the badge above). The in-browser engine and four bundled examples — binary delay discounting, Halberda-style dot comparison, 3IFC categorical line-length, and continuous magnitude estimation (Stevens' power law) — work and are covered by CI (unit tests + real headless Worker/WASM smokes + a bundler build smoke). The committed WASM is bundler-safe and the package builds under Vite and webpack 5 (see Using with a bundler). Still pre-1.0: the model-package and controller APIs may change before 1.0 (task code is ordinary jsPsych experiment code, not a package API).

Quick start

No build step — serve the repo with any static server (VS Code Live Server, etc.) and open the example:

demos/delay_discounting_tutorial/index.html?debug=1
demos/size_discrimination/index.html?debug=1
demos/delay_discounting/index.html?debug=1
demos/line_length_discrimination/index.html?debug=1
demos/halberda_dot_comparison/index.html?debug=1
demos/magnitude_estimation/index.html?debug=1

See demos/README.md for a guided tour: start with the minimal delay_discounting_tutorial/, then the fuller demos (binary, categorical, canvas, and continuous responses), plus two that show how to bring your own task code (demos/byo_task_money_choice/) or bring your own model (demos/byo_model_exponential/).

• debug=1 — per-trial console summary, selection diagnostics when available, live posterior-convergence charts, and a posterior debrief overlay at the end (handled by the library; no demo scaffolding needed).
• Controller/strategy switches (controller: "mock", design_strategy: "random") are ordinary createController options in the experiment code rather than URL flags; the magnitude-estimation demo shows a demo-owned ?simulate=data-only flag wired through the simulate option.

Usage

Your experiment is ordinary jsPsych code: create a controller for a model + design grid, read the current design inside your own trial, and record the response from its on_finish. ado.createTimeline(...) wraps your trial into the adaptive loop and owns the scheduling guarantee — the model update is awaited before the next trial renders (this relies on jsPsych ≥ 8 awaiting async on_finish). The example below is for a bundler project (npm install jspsych-ado); see Using with a bundler for the required setup, and Quick start above for running the in-repo examples by serving the repo statically.

import { initJsPsych } from "jspsych";
import htmlButtonResponse from "@jspsych/plugin-html-button-response";

import { jsPsychADO } from "jspsych-ado";
import hyperbolic from "jspsych-ado/models/hyperbolic/model.js";

const jsPsych = initJsPsych();

const ado = jsPsychADO.createController(jsPsych, {
  model: hyperbolic,
  design_grid: {
    t_ss: [0],
    t_ll: [1, 4, 12, 26, 52],
    r_ss: [100, 200, 400, 600],
    r_ll: [800],
  },
  stan: { num_chains: 2, num_warmup: 500, num_samples: 500, seed: 123 },
  n_trials: 42,
});

const trial = {
  type: htmlButtonResponse,
  stimulus: () =>
    `$${ado.evaluateDesignVariable("r_ss")} now, or ` +
    `$${ado.evaluateDesignVariable("r_ll")} in ${ado.evaluateDesignVariable("t_ll")} weeks?`,
  choices: ["Sooner", "Later"],
  // The recorded value is the MODEL outcome (binary 0/1 here). For button trials the
  // raw response already is the outcome index; keyboard/slider tasks map it first.
  on_finish: (data) => ado.recordResponse(data.response),
};

jsPsych.run([/* instructions, */ ...ado.createTimeline(trial) /*, end screen */]);

One adaptive step can also be an array of trials (fixation → stimulus → response; the last trial collects the response by default) or a trial factory (ctx) => trial(s) — see the halberda demo for a canvas task built this way.

Using with a bundler

The package is ESM and runs client-side only (it spawns a Web Worker that loads the Stan WASM). It is tested against Vite and webpack 5.

• jsPsych plugins. Your trials are ordinary jsPsych trials, so you install and import whichever response plugins your task uses and put them on the trial's type yourself — the library never constructs plugin trials and has no plugin peer dependencies. jsPsych ≥ 8 is the only peer dependency (the scheduling guarantee relies on v8 awaiting async on_finish).
• Vite. The worker and WASM are emitted from new URL(..., import.meta.url) inside the installed dependency. If Vite's dep pre-bundling interferes with that emission, exclude the package: optimizeDeps: { exclude: ["jspsych-ado"] }.
• webpack 5. Works out of the box (first-class new Worker(new URL(...)) and WASM asset support); no extra config needed.
• SSR / Next.js. Build the timeline only in the browser (e.g. behind useEffect / a "use client" component) — the Worker and WASM are not available during server rendering.

API

• createController(jsPsych, { model, design_grid, stan, n_trials, ... }) — validate the model/grid pair and return the controller handle.
• ado.evaluateDesignVariable(key) / ado.designVariable(key) / ado.getDesign() — read the current ADO-selected design inside your trial's dynamic parameters.
• ado.recordResponse(outcome) — record the model outcome from the adaptive trial's on_finish (validated against the model's response space).
• ado.createTimeline(trialOrTrials, options) — wrap your trial(s) into the adaptive loop; options override n_trials, stopping, testlet_size, controller: "mock", design_strategy: "random", debug, response_labels, simulate, ….
• ado.getState() — the live posterior summaries and selection diagnostics.
• prepareModel(spec, { compileServer }) — compile a Stan-source model spec into a model package (prototyping path; committed models skip this).

Adaptive stopping

Beyond choosing each design, the loop can decide when to stop. The criterion uses the same currency as design selection — the expected information gain (EIG = the mutual information I(θ; y | d) between the parameters and the response under a design). It stops once the best available next design's EIG falls below a fraction of the maximum achievable EIG (ln(K) nats for a K-category response): i.e. no remaining stimulus is expected to teach much more. Using a fraction keeps one threshold meaningful across binary and categorical tasks.

Pass a stopping config to createController (or per-timeline to ado.createTimeline):

stopping: {
  eig_fraction: 0.1,   // stop when best next-design EIG < 0.1 * ln(K); omit to disable
  min_trials: 8,       // never stop before this many trials
  max_trials: 42,      // hard cap (defaults to n_trials)
  consecutive: 1,      // require this many sub-threshold refits in a row (de-bounce)
}

Omit stopping (or eig_fraction) for a fixed-length run of n_trials. Each row records ado_should_stop and ado_stop_reason ("eig_fraction" or "max_trials"); the EIG that drove the decision is the grid-max MI in ado_max_mutual_info. A complementary precision-target rule is tracked in #101.

Debug traces

debug=1 prints a readable console summary after each adaptive update — the design presented, the response, posterior mean/sd for the active model parameters, the next selected design, and the local sampling time. In DevTools each summary also has a collapsed details group with tables.

With the Stan controller, debug output also includes posterior draw histograms, an on-page information-gain panel, and a dismissible posterior debrief overlay at the end of the run. The panel plots the mutual information of the design that was actually selected on each trial plus realized information gain after the response. Under design_strategy: "ado", the selected-design MI is the max-MI design by construction; under "random", it is the MI of the randomly sampled design, so it should not be read as an optimality claim. The fast controller: "mock" path does not fabricate these quantitative validation metrics; it remains for timeline/UI smoke testing without WASM.

How it works

The timeline talks to an adaptive controller with two methods — a synchronous start(context) (the first design comes from JS prior draws while the WASM loads in the background) and an async update(trial_data) — each returning the next design plus the current posterior. Swapping the deterministic mock controller for the in-browser Stan controller is the entire abstraction; the timeline never sees Stan or WASM. Scheduling rides on jsPsych 8: the response trial's on_finish is composed with the controller update and awaited, so the next trial can't render until the next design is ready — no hidden plugin trials are injected.

• src/ado/mi_engine.js — model-agnostic mutual-information design selection.
• src/ado/stan_worker.js — one generic Web Worker that runs NUTS off the main thread.
• src/ado/ado_timeline.js — the generic, stimulus-agnostic timeline.
• src/controllers/ — the in-browser Stan controller and the mock controller.
• src/index.js — the jsPsychADO façade (createController).

Repository layout

• src/ — the general, model- and stimulus-agnostic library (engine, worker, controllers, generic timeline, façade). It knows nothing about any task.
• src/models/<name>/ — a pluggable model package: a model.js adapter (params, prior, responseProb or responseProbs, stanData, …) plus its compiled .stan artifacts. Shipped models: hyperbolic (delay discounting), weber_dots (ANS acuity), line_length_discrimination_3ifc (3-way categorical), magnitude_estimation (continuous; Stevens' power law).
• demos/<name>/ — example pages that pair a model with user-authored task code (design grid + jsPsych trials, kept demo-local); see demos/README.md. The demos/byo_model_exponential/ demo even authors its own model (exponential discounting) in-folder. These are how-to examples, not part of the published library.

Adding tasks and models

A task is your experiment code: a design grid plus ordinary jsPsych trials wired to a controller handle — nothing to register or package. A model is a package under src/models/<name>/ (or authored locally, like the BYO demo); the engine, controller, and timeline stay generic. Model compilation steps are in src/models/README.md. For runnable end-to-end walkthroughs, see the bring-your-own-task and bring-your-own-model demos in demos/README.md. Binary models expose responseProb(design, params) -> P(response = 1). Finite categorical models expose responseProbs(design, params) -> [p0, p1, ...]. Continuous models expose a response density responseDensity(design, params, y) (plus moments/entropy/sampler); see the models README.

Development

node --test tests/js/*.test.mjs        # unit tests: MI engine, model adapter, façade, controller + timeline failure paths
node tests/js/stan_recovery.smoke.mjs  # real-WASM smoke: ADO recovers parameters (hyperbolic)
node tests/js/weber_recovery.smoke.mjs # real-WASM smoke: recovers the Weber/ANS model
node tests/js/line_length_3ifc_recovery.smoke.mjs # real-WASM smoke: recovers a 3-param categorical model
node tests/js/magnitude_estimation_recovery.smoke.mjs # real-WASM smoke: recovers the Stevens exponent (continuous)
node tests/js/exponential_recovery.smoke.mjs # real-WASM smoke: recovers the BYO-model demo's authored model
node tests/js/likelihood_parity.smoke.mjs # real-WASM smoke: JS responseProb == compiled Stan, + fixed-seed determinism
node tests/js/stopping_recovery.smoke.mjs # real-WASM smoke: EIG-fraction adaptive stopping
node tests/js/locate_file.smoke.mjs    # real-WASM smoke: emscripten honors the wasm locateFile patch
npm install && npm run test:browser    # headless Worker/WASM browser smokes (puppeteer)
npm run test:bundler                   # npm pack -> Vite build -> headless: hashed WASM loads
npm run patch:wasm                     # re-apply the bundler-safety glue patch after recompiling a model

The likelihood_parity smoke is a correctness guard: every .stan exposes its per-trial choice probability as a transformed/generated quantity, so it checks the JS responseProb/responseProbs (used by the MI engine and the simulator) against the compiled Stan likelihood draw-for-draw — if the two ever diverge, ADO would optimize designs against the wrong model. (The Weber model's JS Phi is an erf approximation, so its parity bound is 2e-6, not machine epsilon.)

CI runs the unit tests, the recovery + locateFile smokes, the headless browser smoke, and the bundler smoke on every PR and push to main. After recompiling any model's main.js, run npm run patch:wasm (CI's unit job fails if a committed main.js is left unpatched).

Releases publish to npm by pushing a vX.Y.Z tag, which triggers .github/workflows/release.yml to re-run the full gates and npm publish --provenance. See RELEASING.md and the CHANGELOG.

Deploying

Serve a demo page such as demos/delay_discounting/index.html or demos/line_length_discrimination/index.html from any static host — no backend. The experiment code, the compiled WASM model, and the vendored sampler (core/tinystan/) are local static assets; the demos load jsPsych and its plugins from a pinned CDN (unpkg), so a deployment needs network access for those. For a fully self-contained / offline build, install jsPsych from npm and bundle it (see Using with a bundler).

Compatibility

Browser/Web-Worker only — the WASM is built with emscripten -sENVIRONMENT=web,worker. Requires jsPsych ≥ 8 (jspsych is a peerDependency, >=8) — the adaptive scheduling relies on v8 awaiting async trial on_finish callbacks; the in-repo demos pin jsPsych 8.2.3 + v2 plugins from a CDN. Development and CI use Node >=20.

Citation

A JOSS paper is in preparation (see paper/). Until it is published, please cite this repository.

License

MIT © The jspsych-ado contributors.
