This is my personal configuration for my systems, managed by the nix language and the lix package manager. I stick to the dendritic pattern, making use of flake-parts. Documentation will explain all concepts I use here. I use this to tinker, deploy, and manage my computers from home and remote. :)

My personal workstation is Stellyrland, most topics here will revolve around that host.

Note:
This is a personal configuration. This is not meant to be forked or used by others.

DOCUMENTATION

CONCEPTS  •  GENERAL  •  DEBUG

🏗️ Architecture

flowchart TD
    INPUTS["flake.nix + flake.lock\nlocked inputs"]

    subgraph FLAKE["flake.nix"]
        IT["generated root\nflake-parts + import-tree"]
    end

    subgraph MODS["modules/"]
        DECL["flake-file input declarations\nkept beside their consumers"]
        AGG["flake.modules.*.*\nreusable NixOS / Darwin / Home Manager aspects"]
        HOSTDATA["flake.hosts.*\nper-host data and aspect composition"]
        MK["mkNixos / mkDarwin\nmodules/nix/lib.nix"]
    end

    DECL -.-> INPUTS
    INPUTS --> IT
    IT --> AGG
    IT --> HOSTDATA
    AGG --> MK
    HOSTDATA --> MK
    MK --> SL["stellyrland\nNixOS · x86_64-linux"]
    MK --> ST["stellyrtop\nmacOS · aarch64-darwin"]
    MK --> PPF["plasmapulsefinale\nNixOS · x86_64-linux"]
    MK --> IRF["ItsRedFlame\nNixOS · x86_64-linux"]

    style INPUTS fill:#363a4f,color:#cad3f5,stroke:#5b6078
    style IT fill:#363a4f,color:#cad3f5,stroke:#5b6078
    style DECL fill:#24273a,color:#f5a97f,stroke:#494d64
    style AGG fill:#24273a,color:#c6a0f6,stroke:#494d64
    style HOSTDATA fill:#24273a,color:#8aadf4,stroke:#494d64
    style MK fill:#24273a,color:#7dc4e4,stroke:#494d64
    style SL fill:#1e2030,color:#8aadf4,stroke:#8aadf4
    style ST fill:#1e2030,color:#a6da95,stroke:#a6da95
    style PPF fill:#1e2030,color:#c6a0f6,stroke:#c6a0f6
    style IRF fill:#1e2030,color:#ed8796,stroke:#ed8796

Loading

📂 Project Structure

.
├── flake.nix                 # Flake entry point
├── flake.lock                # Input lockfile
├── docs/                     # Concepts, workflow notes, and troubleshooting
├── secrets/                  # nix-secrets encrypted secrets
│   └── *.enc
└── modules/                  # Flake-parts modules
    ├── flake-config.nix      # Flake-file declarations and supported systems
    ├── constants.nix         # Shared defaults merged into every host's `host.*`
    ├── treefmt.nix           # Repo-wide formatter configuration
    ├── ai/                   # Declarative Stellxie/Hermes Agent configuration
    │   ├── default.nix       # Home Manager module, package, config, services
    │   └── _*.nix            # Explicitly imported helpers (theme, fetching, Discord)
    ├── factory/              # factory.user: per-user NixOS/Darwin/Home Manager wiring
    ├── hosts/                # Host declarations and host-specific aspect composition
    │   ├── stellyrland/      # NixOS workstation (x86_64-linux)
    │   ├── stellyrtop/       # macOS MacBook (aarch64-darwin)
    │   ├── plasmapulsefinale/ # NixOS desktop (x86_64-linux)
    │   └── ItsRedFlame/      # NixOS gaming/AV box (x86_64-linux)
    ├── users/                # Shared user aspect definitions
    ├── base/                 # Core, Lix, Nix settings, SSH, Tailscale, secrets, users
    ├── nix/                  # Nix, Home Manager, deployment, operational helpers, and flake options
    ├── linux/                # Linux boot, hardware, and storage configuration
    │   ├── boot/
    │   ├── hardware/
    │   └── storage/
    ├── applications/         # User-facing applications, grouped by domain
    │   ├── communication/
    │   ├── development/
    │   ├── gaming/
    │   └── media/
    ├── system/               # Darwin, Homebrew, MIME, XDG, service, and secret definitions
    └── openrgb/              # Peripheral RGB control

✨ Notable Configurations

• Locked Inputs: flake-file declarations live with the modules that own them; flake.nix and flake.lock provide the standard Nix input graph.
• Zero-Boilerplate Imports: flake-file's dendritic output uses import-tree to load non-underscore .nix files under modules/ as flake-parts modules.
• Multi-System Outputs: Per-system formatter and check outputs cover x86_64 Linux, aarch64 Linux, and aarch64 Darwin.
• BORE Scheduler: CachyOS kernel with BORE scheduling. Optimized for the X3D CPU. It's smarter about which workloads get the extra cache vs extra clock.
• ZFS Preservation + Sanoid Snapshots: Every boot rolls back to a blank snapshot, keeping the system declared as configured in preservation.nix. Snapshots are taken daily.
• Boot Security: Secure boot, LUKS encryption, initrd ZFS rollback functionality. Only trusted hardware may access my things.

🛠️ Specifications

• Architecture: Dendritic (Keeps things separate and maintainable as aspects that can be toggled.)
• Framework: Flake-Parts
• OS: NixOS (Unstable) & macOS (Darwin)
• Package Manager: Lix (Community-created Nix variant)
• WM: Hyprland
• Shell: Zsh
• Editor: Neovim (NVF IDE + writing), Zed
• Terminal: Kitty
• Bar/Shell: Noctalia

⚠️ AI Disclaimer

AI is utilized in the development of this system, largely for learning, review, and debugging. I'm still actively learning Nix! More elaboration on my AI morals here.

🐇 Personal AI

I have my own personal assistant, Stellxie. You will see her assist me with commits and audits from time to time.

💻 Hosts

🖥️ Stellyrland (Workstation)

• CPU: AMD Ryzen 9 9950X3D
• GPU: AMD Radeon 7900 XTX 24 GB
• Architecture: x86_64-linux
• Memory: 64 GB DDR5
• Storage: 4.5 TB
• OS: NixOS

💻 Stellyrtop (Personal MacBook)

• CPU: Apple M4
• Architecture: aarch64-darwin
• Memory: 16 GB Unified
• Storage: 512 GB
• OS: macOS (nix-darwin)

🖥️ Plasmapulsefinale (Sibling Laptop)

• Architecture: x86_64-linux
• OS: NixOS

🖥️ ItsRedFlame (Sibling Laptop)

• Architecture: x86_64-linux
• OS: NixOS

📜 Credits & Inspiration

• Vic: for Flake-File.
• Vimjoyer: For inspiring my adoption of the dendritic pattern.
• Hand7s: For inspiring many features I adopted.
• Doc-Steve: For the repo this configuration references architecturally.
