Building a simple network

  • Repository: building_a_simple_network
  • Type of Challenge: Consolidation
  • Duration: 1 day
  • Deadline: 16/03/2024
  • Team challenge : solo

The Mission

Hackers Poulette a young startup that has just been created calls on your services to begin the installation of their infrastructure.

For now, there are only three people working on it, and all on the same set. But Robert Tappan Morris, the CEO, insists on the fact that Hackers Poulette is bound to grow, that the ambitions of the startup are great. So he wants an installation that is easily scalable. All three hosts must also be connected to the internet.

Addressing table :

Devices LAN IP Mask
PC-Robert Eth 192.168.1.10 255.255.255.0
PC-Camille Eth 192.168.1.11 255.255.255.0
PC-Renaud Eth 192.168.1.12 255.255.255.0

Resource Requirements :

  • 1 switch (Cisco 2960 with Cisco IOS version 15.0(2) image lanbasek9 or similar)
  • 3 PCs (Windows 10)
  • Three Ethernet cables

Mission objectives

You will create a simple network with three hosts and a switch. You will apply IP addressing to the computers to allow communication between these three devices. Use the ping utility to verify connectivity between the hosts.

Goals :

  • to be able to create a simple network
  • to be able to configure interconnectivity between hosts
  • to be able to connect hosts to the internet

Must-have features

Use Cisco Packet Tracer to design your infrastructure.

Nice-to-have features

Write a report with the configuration done on the hosts.

Deliverables

  1. Publish your pka file on the GitHub repository.
  2. Pimp up the readme file:
    • What, Why, When, How, Who.
    • Pending things to do
    • It must contain a link to the "live" version. The "live" version must contain a link to the source code on GitHub.
  3. Publish the link to the "live" version on your startup's Discord's channel. ...

Evaluation criterias

Criteria Indicator Yes/No
1. Is complete The student has realized all must-have features.
There is a published GitHub page available.
Computers communicate with each other.
Computers are connected to internet.

Relevant Resources

Are you done?

So, have you created your first network? Ready for the next step?
